Product Code: NEPTUNE-JG
Neptune Mixers
JG Series: JG-2.0 - Single Propeller
Shaft Length: Standard Length
Cup Plate: Keep Standard "C" Clamp
Price:
$3,434.20
Stock:
In stockFREE DELIVERY Availability: Usually Ships in 1 to 2 Weeks

Description

Neptune JG

Neptune JG Series mixers may be ordered online. This is Neptune most powerful mixers for the most difficult mixing applications. Grease filled gearbox eliminates oil seal and the possibility of oil contamination of process

  • No clutches to slip, wear or replace.
  • 316SS propellers and shafts are standard. Optional coatings such as rubber, PVC or Teflon also available.
  • Square pitch 1.0 ratio marine propellers are used exclusively. Flow coefficients and power consumption characteristics equal those of the best hydrofoil impeller designs.
  • Vibration-absorbing pad standard.
  • Motors are available in TEFC or explosion-proof enclosures (1750 rpm, 56C frame). Air motors also available.
  • Gears run in grease lubrication. Cannot leak oil.
  • All JG mixer shaft bearings are permanently lubricated.
  • Variable speed drives also available.
  • Cast aluminum housing.
  • Mounting clamp has adjustable angle of entry by indexed ball-and-socket design to achieve various process results.
  • Fixed cup plate mount optional on 1/3 HP through 1-1/2 HP. Standard on 2 HP and larger models.
Other specifications:
Model Motor Type Shaft
Diameter		 Shaft
Length		 Single Propeller Diameter Dual Propeller Diameter Ship Weight (lbs)
JG-2.0 1/3HP-1-115/230-TEFC* 3/4" 48" 10" 8" 60+
JG-2.1 1/3HP-3-230/460-TEFC* 3/4" 48" 10" 8" 60+
JG-2.2 1/3HP-1-115/230-EP 3/4" 48" 10" 8" 75
JG-2.3 1/3HP-3-230/460-EP 3/4" 48" 10" 8" 75
JG-3.0 1/2HP-1-115/230-TEFC* 3/4" 48" 12" 10" 70+
JG-3.1 1/2HP-3-230/460-TEFC* 3/4" 48" 12" 10" 70+
JG-3.2 1/2HP-1-115/230-EP 3/4" 48" 12" 10" 90
JG-3.3 1/2HP-3-230/460-EP 3/4" 48" 12" 10" 90
JG-3.4
1/3 TO 1/2HP AIR MOTOR**
Air Requirements: 12-20CFM at 40-80PSI
3/4" 48" 12" 10" 65+
JG-4.0 3/4HP-1-115/230-TEFC* 3/4" 60" 13" 11" 80
JG-4.1 3/4HP-3-230/460-TEFC* 3/4" 60" 13" 11" 80
JG-4.2 3/4HP-1-115/230-EP 3/4" 60" 13" 11" 90
JG-4.3 3/4HP-3-230/460-EP 3/4" 60" 13" 11" 90
JG-4.4
3/4HP AIR MOTOR**
Air Requirements: 30CFM at 60PSI
3/4" 60" 13" 11" 70+
JG-5.1 1HP-3-230/460-TEFC* 1" 60" 14" 12" 90
JG-5.3 1HP-3-230/460-EP 1" 60" 14" 12" 100
JG-5.4
1HP AIR MOTOR**
Air Requirements: 40CFM at 4
0PSI
1" 60" 14" 12" 70+
JG-6.1 11/2 HP-3-230/460-TEFC* 1" 60" 15" 13" 90
JG-6.3 11/2 HP-3-230/460-EP 1" 60" 15" 13" 100
JG-6.4
11/2 HP AIR MOTOR**
Air Requirements: 55CFM at 60PSI
1" 60" 15" 13" 75
JG-7.1 2HP-3-230/460-TEFC* 1-1/4" 60" 16" 14" 95
JG-7.3 2HP-3-230/460-EP 1-1/4" 60" 16" 14" 105
JG-7.4
2HP AIR MOTOR**
Air Requirements: 65CFM at 70PSI
1-1/4" 60" 16" 14" 80
JG-8.1 3HP-3-230/460-TEFC 1-1/4" 72" 16" 15" 115
JG-8.4
4HP AIR MOTOR**
Air Requirements: 125CFM at 90PSI
1-1/4" 72" 16" 15" 80


Notes:
* Mill and Chemical Duty Motors available.
** Requires Air Set for use. You may purchase this as an option.
JG-7.1 and greater may only be ordered with a cup mount plate.

We are looking into the Neptune JG-5.1 Mixer for our water treatment setup. When should we use a Dual Propeller vs Single Propeller setup? Dual Propellers are recommended for tanks with 1,000 gal. (3,785.4 L) and larger at viscosities of 1,000 cP and higher.

Shipping and Transit Times

This product is made to order and ships within 7-10 business days from Grand Terrace, CA.

UPS transit map



  • This product only ships UPS. We can not ship Fedex or USPS.
  • We can ship internationally.
  • We can not ship this product to a PO box.
  • If the product is Haz mat. It can not can not air ship.



You will receive the tracking info after the order ships with 48 hours.

For expedited orders please email sales@buychemicalsdirect.com.
We are fast at responding!

If you can not order online, call in your order at 800-658-7716 with specific directions.
